High-Capacity ECC DDR4 Memory for Reliable Virtualization
The QNAP TS-H1277XU-RP is a powerful NAS server model equipped with up to 128GB DDR4 ECC UDIMM RAM. Designed for enterprise virtualization and data-intensive applications, it delivers exceptional reliability and performance for demanding IT environments.
💾 Capacity & Configuration
- Capacity: 128GB total memory, configurable across four Long-DIMM slots
- Channels: Dual-channel memory support for enhanced throughput
- Module Count: Up to four ECC UDIMM memory modules (maximum 128GB)
⚡ Speed & Performance
- Memory Type: DDR4 ECC UDIMM, providing error-correcting code for data integrity
- Speed: Supports up to 3200MHz (typical for Ryzen 7 3700X platforms)
- Timings: Industry-standard CAS latency (exact timings dependent on module)
- Bandwidth: High throughput for virtualization and multi-tasking workloads
- XMP/EXPO Profile: Not specified; optimized for stability in NAS environments
🔧 Compatibility
- Form Factor: UDIMM suitable for server and workstation memory slots
- Platform Support: Fully compatible with AMD Ryzen 7 3700X processors and enterprise NAS systems
- ECC Support: Yes, Error Correcting Code for improved data integrity and system stability
- Tested Systems: Verified in QNAP TS-h1277XU-RP NAS servers optimized for virtualization and storage
🌡️ Reliability & Build
- Operating Voltage: Standard 1.2V DDR4 specification
- Operating Temperature: Compliant with typical server hardware temperature ranges
- Heat Spreader: Not specified; designed for optimal thermal performance in rackmount chassis
📦 What's in the Box
- Memory module(s) according to kit configuration
- Product documentation and installation guide
🛡️ Warranty
Backed by a manufacturer’s warranty (specific duration not provided).
Experience superior multitasking, virtualization support, and data integrity with QNAP’s server-grade ECC DDR4 memory – engineered for demanding IT environments.
| Storage | |
|---|---|
| Storage drives installed | No |
| Installed storage drive type | No |
| Supported storage drive types | HDD & SSD |
| Number of storage drives supported | 12 |
| Online RAID migration | Yes |
| Online RAID expansion | Yes |
| RAID support | Yes |
| RAID levels | 0, 1, 5, 6, 10, 50, 60, JBOD |
| Hot-swap drive bays | Yes |
| Supported storage drive interfaces | Serial ATA II, Serial ATA III |
| Storage drive sizes supported | 2.5,3.5" |
| Processor | |
| Processor manufacturer | AMD |
| Processor family | AMD Ryzen™ 7 |
| Processor threads | 16 |
| Processor operating modes | 64-bit |
| Processor boost frequency | 4.4 GHz |
| Processor model | 3700X |
| Processor frequency | 3.4 GHz |
| Processor cores | 8 |
| Memory | |
| Internal memory type | DDR4 |
| Internal memory | 128 GB |
| Maximum RAM supported | 128 GB |
| Memory slots | 4 |
| Flash memory | 5000 MB |
| Memory form factor | UDIMM |
| Network | |
| Ethernet LAN data rate supported (max) | 10000 Mbit/s |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 1000,10000 Mbit/s |
| Wi-Fi | No |
| Jumbo frames support | Yes |
| Ports & interfaces | |
| USB port | Yes |
| Ethernet LAN (RJ-45) ports | 4 |
| PCI Express x8 (Gen 3.x) slots | 2 |
| PCI Express x4 (Gen 3.x) slots | 2 |
| Fiber ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| Design | |
| Chassis type | Rack (2U) |
| Product colour | Black, Grey |
| Cooling type | Active |
| Number of fans | 2 fan(s) |
| Fan diameter | 7 cm |
| LED indicators | HDD, LAN, Status |
| Performance | |
| Type | NAS |
| Device class | Small & Medium Business |
| Backup function | Yes |
| Backup features | Cloud, iSCSI LUN |
| Buzzer | Yes |
| Multilingual support | Yes |
| Noise level | 37.2 dB |
| Operating system installed | QNAP QTS |
| Operating system version | 5.0.0 |
| Reset button | Yes |
| On/off switch | Yes |
| Windows operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Software | |
| Operating system installed | QNAP QTS |
| Operating system version | 5.0.0 |
| Windows operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Power | |
| Power supply location | Built-in |
| Power supply unit (PSU) capacity | 300 W |
| Number of power supply units | 2 |
| Redundant power supply (RPS) support | Yes |
| Power consumption (typical) | 106.66 W |
| AC input voltage | 100 - 240 V |
| Fan voltage | 12 V |
| Weight & dimensions | |
| Width | 482 mm |
| Depth | 562 mm |
| Height | 88.3 mm |
| Weight | 13.7 kg |
| Package weight | 16 kg |
| Technical details | |
| Harmonized System (HS) code | 84714100 |
| Packaging content | |
| Number of screws | 84 |
| Quick installation guide | Yes |
| Cables included | AC, LAN (RJ-45) |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage temperature (T-T) | -20 - 70 °C |
| Logistics data | |
| Harmonized System (HS) code | 84714100 |
QNAP TS-H1277XU-RP – 128GB DDR4 – ECC UDIMM RAM
