| Processor |
|---|
| Processor base frequency | 3.6 GHz |
| Processor manufacturer | Intel |
| Cooler included | Yes |
| Processor codename | Skylake |
| Memory bandwidth supported by processor (max) | 85.3 GB/s |
| Thermal Design Power (TDP) | 120 W |
| Processor cache | 8.25 MB |
| Processor ARK ID | 125036 |
| Processor family | Intel® Xeon® |
| Processor cores | 4 |
| Processor socket | LGA 2066 (Socket R4) |
| Component for | Server/workstation |
| Processor lithography | 14 nm |
| Box | Yes |
| Processor model | W-2123 |
| Processor threads | 8 |
| System bus rate | 8 GT/s |
| Processor operating modes | 64-bit |
| Processor boost frequency | 3.9 GHz |
| Stepping | U0 |
| Bus type | QPI |
| Processor code | SR3LJ |
| Memory |
|---|
| Maximum internal memory supported by processor | 512 GB |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 1600,1866,2133,2400,2666 MHz |
| Memory bandwidth supported by processor (max) | 85.3 GB/s |
| Supported memory types | DDR4-SDRAM |
| Memory channels | Quad-channel |
| ECC | Yes |
| Graphics |
|---|
| On-board graphics card | No |
| Power |
|---|
| Thermal Design Power (TDP) | 120 W |
| Features |
|---|
| Maximum number of PCI Express lanes | 48 |
| Thermal Design Power (TDP) | 120 W |
| Processor package size | 45mm x 52.5mm |
| Processor ARK ID | 125036 |
| Thermal Monitoring Technologies | Yes |
| Idle States | Yes |
| Execute Disable Bit | Yes |
| PCI Express slots version | 3.0 |
| PCI Express configurations | 1x16, 1x4, 1x8 |
| Supported instruction sets | SSE4.2, AVX, AVX 2.0, AVX-512 |
| Scalability | 1S |
| Physical Address Extension (PAE) | Yes |
| Embedded options available | No |
| CPU configuration (max) | 1 |
| Processor code | SR3LJ |
| Physical Address Extension (PAE) | 46 bit |
| Market segment | Server |
| Harmonized System (HS) code | 85423119 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | G077159 |
| PCI Express CEM revision | 3.0 |
| Processor special features |
|---|
| Intel Software Guard Extensions (Intel SGX) | No |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel 64 | Yes |
| Conflict-Free processor | Yes |
| Intel Turbo Boost Max Technology 3.0 | No |
| Intel® Memory Protection Extensions (Intel® MPX) | Yes |
| Intel® Device Protection Technology (Intel® DPT) with Boot Guard | Yes |
| Intel® Speed Shift Technology | Yes |
| Intel® Optane™ Memory Ready | No |
| Intel® Turbo Boost Technology | 2.0 |
| Intel Trusted Execution Technology | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel Flex Memory Access | No |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel® OS Guard | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel TSX-NI | Yes |
| Intel® Secure Key | Yes |
| Intel Enhanced Halt State | Yes |
| Intel Demand Based Switching | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Secure Key Technology version | 1.00 |
| Intel Identity Protection Technology version | 1.00 |
| Intel TSX-NI version | 1.00 |
| AVX-512 Fused Multiply-Add (FMA) units | 2 |
| Intel® Boot Guard | Yes |
| Intel® Volume Management Device (VMD) | Yes |
| Intel® vPro™ Platform Eligibility | Yes |
| Intel® Transactional Synchronization Extensions | Yes |
| Operational conditions |
|---|
| Tcase | 65 °C |
| Technical details |
|---|
| Product type | Processor |
| Processor cache | 8448 KB |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel 64 | Yes |
| Thermal Design Power (TDP) | 120 W |
| Supported memory types | DDR4-SDRAM |
| Status | Launched |
| Physical Address Extension (PAE) | 46 bit |
| Market segment | Server |
| Launch date | Q3'17 |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Secure Key Technology version | 1.00 |
| Intel Identity Protection Technology version | 1.00 |
| Bus type units | GT/s |
| Processor brand name | Intel Xeon |
| Maximum memory | 512 GB |
| Intel TSX-NI version | 1.00 |
| Last change | 63903513 |
| Product family | Intel Xeon Processors |
| Intel® Speed Shift Technology version | 1.00 |
| Intel® Volume Management Device (VMD) version | 1.00 |
| AVX-512 Fused Multiply-Add (FMA) units | 2 |
| Harmonized System (HS) code | 85423119 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | G077159 |
| Bus speed | 8 GT/s |
| Packaging data |
|---|
| Package type | Retail box |
| Weight & dimensions |
|---|
| Processor package size | 45mm x 52.5mm |
| Other features |
|---|
| Maximum internal memory | 524288 MB |
| Maximum internal memory | 512 GB |
| CPU configuration (max) | 1 |
| Processor code | SR3LJ |
